| Technical Specification |
| Compatibility: |
BROCADE |
| Connector Type: |
Duplex LC |
| DOM: |
Yes |
| Form Factor: |
QSFP28 |
| Media Type: |
SMF |
| Maximum Link Length: |
40KM W/ FEC |
| Speed: |
100G |
| Transceiver Type: |
100GBASE-ER4 |
| Wavelength: |
1271nm-1331nm |
| Optical Specification |
| Optical Power |
-2.5dBm to 6.5dBm (Per Lane) |
| RX Sensitivity |
-17dBm (Per Lane) |
| Physical Specification |
| Shipping Dimension |
1.2 in. x 2.75 in. x 4.75 in. |
| Shipping Weight |
0.4 |
| Miscellaneous |
| Country Of Origin |
USA |
| HTS-Harmonized Code (US) |
8517.70.0000 |
| ECCN |
5A991 |
| Compliance: |
TAA, RoHS, MSA, IEEE 802.3z
|
